NOTEBOOK PROPER CARE

Hp notebook

1000 Fix Services Ltd.


Home
background image

2

Session Outline

Part 1.

Environmental tips for HP notebooks

Part 2.

Electrical tips for HP notebooks

Part 3.

Transportation tips for HP notebooks

Part 4.

Part 5.

Cleaning tips for HP notebooks

Part 6.

Primary Diagnosis

Battery tips for HP notebooks


background image

First Part-

Environmental tips for HP notebooks

3

❖ Do not use the notebook on your lap or let its warm

surfaces make direct contact with your skin. If you want to
use it on your lap, rest it on a hard, flat surface, such as a
lap tray specifically designed for notebooks.

❖ Do not use the notebook on soft surfaces, such as bed

comforters, cushions and pillows, clothing, or carpet. Such
surfaces can block the air flow through the vents, which
can cause heat to build up within the notebook's
enclosure.

1. Use your notebook on a hard surface, such as a desk, tray, or table


background image

First Part-

Environmental tips for HP notebooks

4

2. Use or store your notebook in environment that conform to

temperature and humidity specifications

❑ Excessive heat can damage key components in the notebook system

❖ Do not leave the notebook in a hot enclosure, such as a parked car, or in

direct sunlight. Either of these can cause heat damage and warping.

❖ Keep the LCD display out of direct sunlight for extended periods of time.
The notebook is designed to automatically throttle its activity when its
internal temperature exceeds predefined levels.

❖ If its temperature rises too high, the notebook is designed to shut itself

down to protect its internal components.

❖ For detailed information about heat-related performance, refer to

Fan is

Noisy and Spins Constantly, PC is Warmer than Normal

.

❖ For detailed information about heat and how it can affect the notebook

battery, refer to

Battery Charging Delayed When Operating Notebook in

High Ambient Temperatures

.


background image

First Part-

Environmental tips for HP notebooks

5

2. Use or store your notebook in environments that conform to

temperature and humidity specifications

❑ Excessive cold can prevent a battery from charging and operating properly

Note: Excessive heat or cold can damage your notebook computer and

prevent it from operating properly.

❖ The typical Lithium-Ion battery used in HP notebook computers cannot

charge properly at temperatures of

30 to 50 degrees F (0 to 10 C).

At

these temperatures, the battery charges extremely slowly and cannot
acquire a full charge before the charging cycle times out.

❖ For proper operation, move the notebook to a warmer environment

where the internal temperature of the battery can rise above

50 degrees F

(10 degree C).

❖ If the battery is left in a low temperature environment for 12 hours or

more, you must warm the notebook and battery and then perform a hard
reset of the notebook.

For detailed information on performing a hard or forced reset, refer
to

Performing a Hard Reset or Forced Reset

.


background image

First Part-

Environmental tips for HP notebooks

6

3. Use or store the notebook in a clean environment

❖ Do not use or store the computer in an environment

characterized by

high humidity, dust, grit, or smoky

conditions.

❖ Notebook computers have vents on the bottom and

sides to allow air to flow through the inside and cool
the internal parts. If these vents become clogged or
the heat generating parts get covered in dust, the fan
cannot cool the internal components properly.

❖ Blow compressed air into the outlet vents to remove

the dust that has accumulated and keep the air
circulating through the device.
For detailed information about keeping the vents clear,

refer to

Reducing Heat Inside the PC

.


background image

First Part-

Environmental tips for HP notebooks

7

4. Use clean hands while using the notebook

❖ Do not use the keyboard with sticky, dirty, or greasy

fingers. This can leave debris behind, which can
easily contaminate the computer's internal
components. Debris on the keyboard can also scratch
and stain the notebook display when the lid is
closed.


background image

First Part-

Environmental tips for HP notebooks

8

❑ Keep all liquids away from the keyboard

❖Keep all liquids, such as coffee, cola, water, or cleaning

solvents away from the keyboard.

❖Do not eat or drink while using a notebook.

❖Do not use the computer in any wet environment, such

as a swimming pool or shower, and protect the
components from liquid sources, including rain and
lawn sprinklers.


background image

First Part-

Environmental tips for HP notebooks

9

❑ Store the notebook on a hard flat surface

❖Do not store a notebook at the bottom of a

locker, in a bag full of books, or under
anything that can exert enough stress to crack
the case or the display.

❖Do not stack items on top of the notebook

computer.


background image

10

Second Part-

Electrical tips for HP notebooks

1. Use only the power adapter that came with your HP notebook

❖ For best performance, use only the power adapter that came with

your HP notebook and configure your power management settings for
optimal performance based on your usage habits.

❖ For instructions on how to improve battery performance,

see

Improving Battery Performance (Windows)

.

❖ Most HP notebooks utilize smart power adapter technology. They can

use power adapters from other HP notebooks that might have
different wattage requirements.

❖ If you use a power adapter that has a lower wattage than your

notebook requires, there might be some trade-offs. The CPU clock rate
might be reduced to save power, which can cause programs to run
slower, the battery might charge more slowly or not at all, or the
power adapter itself might become warm to the touch.

❖ Your power adapter's wattage information is printed on the bottom of

the adapter itself.


background image

11

Second Part-

Electrical tips for HP notebooks

2. Always plug your notebook power supply into a grounded outlet

❖If you do not use a grounded outlet, you might notice

an electrical tingling sensation where the palms of
your hands touch the notebook during use.

❖All power adapter certification tests for HP notebook

computers are performed using a grounded power
adapter. Damage can occur if an ungrounded power
adapter is subjected to power surges or electrostatic
discharge.


background image

12

Second Part-

Electrical tips for HP notebooks

3. Always store your notebook power cord loosely in a bundle

❖ Gather the power cord loosely in a bundle when

packing it away for storage or transport.

❖ Use a "figure 8" pattern when bundling the cord.

This allows for easy storage of the cord, prevents
unintentional breaks in the wires, and keeps it from
getting tangled.


background image

Second Part-

Electrical tips for HP notebooks

4. Never wrap your notebook power cord around the power adapter

or any other object

❖Do not wrap the power cord around

the power adapter or any other object
as this could inadvertently break the
cord's internal copper wires.


background image

14

Second Part-

Electrical tips for HP notebooks

5. Use the notebook power adapter on a hard, flat surface

❖ When a high number of applications

are running or when the battery is
recharging, the power adapter might
be warm to the touch when it reaches
its power limit.

❖ Connect the power adapter to a good

quality surge protector if your local
power supply is unstable.


background image

Third Part-

Transportation tips for HP notebooks

1. Shut down your notebook computer before transporting

❖Ensure the notebook is fully powered down when

carrying it in a carrying case by either putting it in
Hibernate mode or completely shutting the
notebook down using the Shut Down button. Closing
the lid by itself might not automatically shut the
notebook down completely.

❖Do not put the notebook in a carrying case, bag, or

backpack while the power is on or the notebook is in
Standby or Sleep mode; all LED lights should be dark.
This might cause heat to build up in the notebook.


background image

Third Part-

Transportation tips for HP notebooks

2. Fully close the notebook lid prior to carrying it

❖ Close the notebook, with nothing in between the lid

and the keyboard, prior to carrying it.

❖ Do not put objects, such as pens and paper, between

the keyboard and screen and then attempt to carry
the partially closed notebook. If the objects move,
they can scratch or damage the LCD screen. If
pressure is applied to the case and cover, the objects
can damage the LCD.

❖ Remove the packing material from between the

keyboard and display when you first take the
notebook out of its box.


background image

Third Part-

Transportation tips for HP notebooks

3. Carry the notebook securely

❖ Carry the notebook securely, with the lid closed, under one arm or

using both hands to hold it. Alternately, use a briefcase or a backpack
to carry the notebook. If the computer will be subjected to potential
high stress movements (dropping or banging into other objects) carry
it in a zero-impact case.

❖ Verify that the battery is locked into place when using an extended or

external battery in order to prevent it from coming loose during
transport.

❖ Do not carry the notebook with the lid open, or by the hinges. Never

pick up or carry the notebook by the LCD screen or lid. Whenever
possible, lift the notebook by the lower case with the lid closed. The
hinges are not designed to handle the full weight of the notebook.
Carrying the notebook while it is open leaves the notebook vulnerable
to damage if you drop it as a result of carrying it in such a manner.


background image

Third Part-

Transportation tips for HP notebooks

4. Do not overload the briefcase or backpack

❖ To protect the LCD panel from potential damage that

might be caused by squeezing the notebook, use a
properly-sized briefcase or backpack and avoid
overloading the briefcase or backpack or adding heavy
objects.


background image

Third Part-

Transportation tips for HP notebooks

5.

Unplug all cords and peripheral devices before moving a

notebook

❖ Always unplug the power adapter cord, mouse, and any

other peripheral devices before moving a notebook
computer.

❖ Leaving accessories or power adapters connected to a

notebook while moving it can damage the accessories
and break the notebook connectors. Pulling, twisting, or
jamming cords can damage the cords.


background image

Third Part-

Transportation tips for HP notebooks

7.

Use a security device when using a notebook in a public location

❖ When using a notebook in a public location, such as a

café or a library, use a security device, such as a locking
device, to help deter theft.

❖ Do not leave a notebook unattended.


background image

1. Conserve battery power

It is important to be
aware of ways that
you can care for the
battery in your
notebook computer.
Certain conditions
might reduce battery
run time and life span.

Fourth Part-

Battery tips for HP notebooks

❑ Use these tips to change the power consumption of the computer to conserve battery

power.

1.Reduce the number of open applications

. Each open software application uses

memory and power, even when the application window is minimized. Close software
applications to conserve battery power.

2.Reduce the brightness of the screen to the minimum readable level

. Use the

function keys to adjust the brightness or use the display settings in Windows.

3.Remove peripherals when not in use

. External hard drives and other peripheral

devices can draw power from your battery even when they are not in use. Disconnect
peripheral devices when you are finished using them.

4.Reduce the speed of your processor.

The faster your computer works, the more

quickly it depletes battery power. You can extend the charge of your battery by slowing
down the processor speed.

5.Turn off the wireless function

. Wireless connections draw battery power. When

wireless capability is not needed, turn it off. Press the Wireless On-Off button so that the
wireless feature and wireless light turn off.

6.Change the power option setting.

Select either HP Recommended or Power

saver to conserve battery power.


background image

1.

Adjust power plans

Fourth Part-

Battery tips for HP notebooks

❖ A power plan is a collection of hardware and system settings

that manage how your computer uses power. Power plans
can help you save energy, maximize system performance, or
achieve a balance between the two.

❖ In Windows, search for and open Choose a power plan to

learn about, customize, and choose a power plan.

❑ Change power plans to meet performance needs

❖ Power plans are a collection of hardware and system

settings that manage how your computer uses power. Select
from preset power plans that use less power, maximize
performance, or balance the two. You can also create
custom plans according to specific performance needs

.


background image

1.

Adjust power plans

Fourth Part-

Battery tips for HP notebooks


background image

1.

Adjust power plans

Fourth Part-

Battery tips for HP notebooks


background image

1.

Adjust power plans

Fourth Part-

Battery tips for HP notebooks


background image

1.

Adjust power plans

Fourth Part-

Battery tips for HP notebooks


background image

2. Shut down or restart the computer

Windows includes a normal shut down for faster startup times, or perform a full
shut down for long term storage, component upgrades, or when diagnosing
issues.

Normal shut down

Use this option under normal operating conditions. This

closes open programs, logs you out, and turns the computer off. By default, fast
startup mode is enabled with this option. A hibernation file is saved before
shutting down so the computer starts up faster next time you turn it on.
To perform a normal shut down, click the Windows icon

click

Power

, and then click

Shut down

.

Full shut down

Use this option for long term storage or shipping, when

performing hardware upgrades, when opening the BIOS Setup Utility, or to
change UEFI settings and run tests.
To perform a full shut down, click the Windows icon, click

Power

, press and hold

the Shift key, and then click

Shut down

.

Restart

Use this option after installing software that requires a system restart,

such as new drivers, Windows updates, and virus scanning software.
To perform a reset, click the Windows icon, click

Power

, and then click

Restart

.

Fourth Part-

Battery tips for HP notebooks


background image

3. Use sleep mode

Fourth Part-

Battery tips for HP notebooks

❖ When the computer is not active for a period of time, sleep

mode places the computer into a low power state to conserve
energy. In this mode, all apps remain open for a quick startup
when you return to the computer.

❖ This mode uses very little power and is recommended if you

are away from the computer for a little while. You can
manually enter sleep mode or set the computer to
automatically sleep after a certain time of inactivity.

❖ To manually enter sleep mode, click the Windows icon

click

Power

, and then click

Sleep

. Continue with these steps to

change when the computer automatically enters sleep mode.


background image

3. Use sleep mode

Fourth Part-

Battery tips for HP notebooks


background image

3. Use sleep mode

Fourth Part-

Battery tips for HP notebooks


background image

3. Use sleep mode

Fourth Part-

Battery tips for HP notebooks


background image

Cleaning tips for HP notebooks

❖ Dust, dirt, ash, pet hair, and other contaminants

can

accumulate on or inside your notebook, causing scratches or
overheating. You can extend the life of your notebook by
removing potentially damaging build up. Clean your
notebook on a regular basis.

❖ HP recommends the following cleaning materials:

❖ Compressed air spray

, which is available from most computer

retailers.

❖ For detailed information about keeping your notebook clean

❖ Cleaning solution or monitor wipes intended

for use on LCD

screens, which are available from most computer retailers.

❖ A clean, soft cotton cloth

; the type of cleaning towel used for

eyeglasses is preferable. For cleaning parts such as the HP
webcam lens, use a micro fiber screen dusting cloth.


background image

Cleaning tips for HP notebooks

HP PCs - How to Clean Your Computer

This document pertains to all HP PCs.

❖ Learn how to clean your computer to remove dirt and debris and use a CDC-

recommended disinfectant on high-touch surfaces like the mouse, keyboard, and
touchscreen.

❖ The Centres for Disease Control and Prevention (CDC) recommends cleaning surfaces,

followed by disinfection, as a best practice for the prevention of viral respiratory
illnesses in households and community settings.

❖ NOTE: There may be some visible changes to cosmetic finishes of your product over

time as a result of the cleaning techniques mentioned in this document.

WARNING:

Before cleaning the computer, perform these steps to reduce the risk of

electrical shock:
Turn off the computer.

Disconnect the power cord from the computer.


background image

Cleaning tips for HP notebooks

How to clean I/O ports

❖ After cleaning the cooling vents, take the

compressed air and blow out any debris that may
have accumulated in and around the ports on the
back, sides, or front of the computer.


background image

Cleaning tips for HP notebooks

How to clean the screen or display

❖ To clean smudges from the LCD screen, choose a non-abrasive cloth or towel. Turn off the

computer and disconnect the power cable. Wipe the screen gently with a soft, dry cloth.
If any marks remain, moisten the cloth with LCD cleaner, and then gently stroke the cloth
across the display in one direction, moving from top to bottom.

❖ If you are cleaning the screen of a notebook PC, be sure the LCD screen is dry before

closing it or using the computer.

CAUTION:

Isopropyl alcohol is a flammable liquid.

Never spray or pour any liquid directly on the LCD screen.

Do not clean the screen while the system is on.

NOTE:

Do not use any of the following chemicals or any solutions that contain them:

Acetone, ethyl

alcohol, toluene, ethyl acid, ammonia, or methyl chloride.

If you have a different chemical or solution and are not sure whether it is suitable, do not use it. Using
any of the chemicals in the previous list may cause permanent damage to the LCD screen. Some
commercial window cleaners contain ammonia and are therefore unacceptable.


background image

Cleaning tips for HP notebooks

How to clean the keyboard

❖ If a small vacuum cleaner with a brush attachment is

available, use it to clear the keyboard of debris.

❖ A can of compressed air can be used to blow out

particles that get in between the keys.


background image

Primary Diagnosis

Primary Diagnosis of the following issue

1. Computer is slow

2. Blue Screen Issue

3. WIFI signal week

4. Not Charging issue

5. Display Flickering

6. No Display

7. No Power


background image

❑ Primary Diagnosis

Computer is slow

Computer or laptop slow in performance? Run regular maintenance to enhance

the performance of your computer. Use the tools in this section to

Optimize your PC and speedup your laptop

Clean up junk files

Control when applications run

Adjust how your computer uses memory resources

Reduce heat inside your computer

Use our automated solutions to run regular maintenance of your computer or

laptop and ensure that the device is performing optimally.

Computer is slow


background image

❑ Primary Diagnosis

❖ Run the HP PC Hardware Diagnostic tests to determine whether the

computer is functioning properly.

•1. Click on Download button and install the latest HP PC Hardware Diagnostics.

Download

•2. After Installation, select Start from your PC, and then under All Apps, select HP Help
and Support, then HP PC Hardware Diagnostics Windows.

•3. The app opens to the main menu. Click computer is slow.

•4. From the component test menu, select Processor test and start the test.

•5. If the hardware test Passed, it indicates there is no Hardware Failure. In case, the test
Failed, it will display an error code.

Hardware Diagnostic

Computer is slow


background image

❑ Primary Diagnosis

❖There are few more terrifying things than coming face to

face with the blue screen of death (BSOD). Maybe you’re
rebooting your computer or you’ve just updated your PC
and now your device is unusable. You’re at risk of losing
valuable files, especially if they haven’t been backed up.

❖Don’t panic! There are some common fixes for this

unsettling screen warning so let’s dive into it so you can
get back to your regular computing.

What is the Blue Screen of Death in Windows 10 and How to Fix it?

Blue Screen Issue


background image

❑ Primary Diagnosis

❖The blue screen of death is also called a stop message or

stop error. Colloquially, it’s known as the blue screen of
doom, bug-check screen, system crash, or simply blue
screen error. It signifies a system crash stemming from
internal issues that we will explore in-depth below.

What is the blue screen of death?

Blue Screen Issue


background image

❑ Primary Diagnosis

❖ Typically, BSODs result from driver software or issues with hardware. Apps that

crash sometimes cause blue screens of death if they’re broken or flawed.

❖ Windows creates what’s known as a minidump file when a BSOD happens. This file

contains information about the crash and saves it to the disk. However, in most cases,
Windows automatically restarts when a blue screen appears.

If you want more time to see what the minidump file is or to see if it’s a blue screen
❖ happening at all, you can disable automatic restarts on BSODs from the Windows

Control Panel.

When your PC restarts after a blue screen, it goes through an automatic troubleshooting
and repair process on its own. However, if Windows can’t repair the issue, you can start to
troubleshoot your own.

If you can isolate the actual Stop Error number or code, you can search the web for the
cause of the exact error. Or refer to this helpful list of common BOSD error codes and their
meanings.

What causes the blue screen of death?

Blue Screen Issue


background image

❑ Primary Diagnosis

❖ First, figure out if you took any actions before the BSOD occurred.

Did you install a new

program, update a driver, or initiate other software changes?

If you did any of these

things, that may be what caused the BSOD.

❖ Undo your last action and test for the STOP Error message. Depending on the change that

occurred, these fixes may work:

•Start your PC using the Last Known Good Configuration

•Utilize System Restore

•Go back to the previous device driver before your latest update
If these do not fix the problem here are some things to check:
1. Check for driver space because if there’s not enough, it may cause a BSOD to rear its ugly blue head
Pro tip: We recommend Windows users aim to keep around 15% of their drive space free for optimal
PC operation.

2. Check the device’s temperature

A device that’s overheating can lead to a system crash and a blue screen of death. Make sure that your
PC has adequate cooling systems so you don’t risk this problem.
3. Scan for malware and viruses

How do I fix the blue screen of death on Windows 10?

Blue Screen Issue


background image

❑ Primary Diagnosis

4. Look for any patches

Microsoft provides patches and service packs for operating systems that may include fixes
for your BSOD.

5. Update drivers for your hardware

Updating your drivers can fix your STOP error in some instances.

6. Check the System and Application logs in Event View to spot possible errors

7. Change your hardware settings to default in Device Manager.

If you have customized settings, that could be the root issue for your BSOD.

8. Ensure you have default BIOS settings.

9. Have you recently tried to install new memory or expansion cards?

How do I fix the blue screen of death on Windows 10?

Blue Screen Issue


background image

❑ Primary Diagnosis

Double-check that the components were installed and seated correctly.

10. Use diagnostic tests to find out if you have malfunctioning hardware somewhere in
your computer since that’s often the culprit behind a blue screen

11. Update your BIOS
If your BIOS is out-of-date, it could lead to system crashes.

12. Start your PC with essential hardware

This is a good way to test what hardware is working and what isn’t.

13. Reinstall Windows
This wipes the slate clean and starts the operating system fresh. However, it should only be
an action you use as a last resort because it will restore your entire computer to factory
settings, erasing any files.

How do I fix the blue screen of death on Windows 10?

Blue Screen Issue


background image

WIFI signal week

WIFI signal week

Run the HP PC Hardware Diagnostic tests to determine whether the Wired /
Wireless Networking is functioning properly.

1. Click on Download button and install the latest HP PC
Hardware Diagnostics.

Download

•2. After Installation, select Start from your PC, and then under
All Apps, select HP Help and Support, then HP PC Hardware
Diagnostics Windows.

•3. The app opens to the main menu. Click Component Tests,
then Networking.

•4. Check the test you want to run, and then click the Run Once
button. Follow the instructions on the screen.
•5. If the hardware test Passed, it indicates there is no Hardware
Failure. In case, the test Failed, it will display an error code.


background image

How to Fix a Laptop That Won't Charge

How to Fix a Laptop That Won't Charge

❖ What would your digital world look like without your laptop?

Your ultra-portable PC is the key to keeping you connected
whether you’re in the office, at home, in the car, or 30,000
feet in the air. You depend on your laptop’s battery to keep
you productive all day and night, but what happens when
your battery stops charging?

❖ When you plug your laptop into a power source, you’re

usually greeted by a chirpy ding or a tiny LED light that
reassures you that all is well in the battery department.
However, if you’ve found that connecting your laptop’s AC
adapter brings no such animation, something may be
seriously wrong.


background image

How to fix a laptop that won’t charge

How to fix a laptop that won’t charge

1. CHECK TO SEE IF YOU’RE PLUGGED IN

2. CONFIRM YOU’RE USING THE CORRECT PORT

3. REMOVE THE BATTERY

If your laptop comes with a removable battery, follow these
steps:
Step 1. Remove any bolts or screws and take out the battery
Step 2. Hold the power button down for 10-15 seconds
Step 3. Plug the charger in
Step 4. Power the PC on

4. EXAMINE YOUR POWER CORDS FOR ANY BREAKS OR
UNUSUAL BENDING


background image

How to fix a laptop that won’t charge

How to fix a laptop that won’t charge

5. UPDATE YOUR DRIVERS
Sometimes all your PC needs is a swift re-up on driver updates to
be restored back to its original health. Follow these steps to
update your Windows 10 laptop’s battery drivers.

Step 1

Right-click the Start menu to open the

Quick

Access

menu and select

Device Manager

Step 2

Under

Batteries

, open the drop-down menu and right-

click

Microsoft ACPI Compliant Control Method Battery

Step 3

Within the new selection window, press

Update Driver


background image

How to fix a laptop that won’t charge

How to fix a laptop that won’t charge

6. SURVEY THE HEALTH OF YOUR CHARGING PORT

7. LET YOUR PC COOL DOWN

8. SEEK PROFESSIONAL ASSISTANCE

When you’ve exhausted all of your options and you’ve tried every troubleshooting
tip and trick, your next best bet will be seeking professional assistance. At the end
of the day, computers are incredibly complex pieces of machinery and sometimes
require a professional touch when it comes to fixing and configuring.
Reach out to your PC’s manufacturer to get in contact with a knowledgeable
professional who may know how to treat your exact make and model. If you’re in
need of immediate in-person help, schedule an appointment with a seasoned
tech repairman who can diagnose and repair on site.


background image

How to Stop Laptop Screen Flickering

How to Stop Laptop Screen Flickering

❖ Computer problems are a headache, and a flickering laptop

screen can definitely cause one. It can destroy productivity in
the office, and turn a couch-cinema experience into a royal
inconvenience. The constant blinking only serves to distract
and frustrate, so the moment it starts, you’ll be in need of a
quick solution.

❖ Fixing a flickering laptop screen doesn’t necessarily require a

trip to the PC repair shop. Solutions as simple as lowering and
raising the screen repeatedly or updating your graphics card
drivers may solve your blinking screen dilemma. But what
causes a laptop screen to flicker and what are the many fixes
that work to stop it? This guide will answer all of your burning
questions.


background image

How to Stop Laptop Screen Flickering

Why is my laptop screen flickering?

❖ The causes behind laptop screen flickering on Windows 10

PCs can be boiled down to a few common culprits.

An aging PC

shows signs of regular wear and tear as years pass by, and
loosened internal cables can create a number of nasty glitches

Newer computers with screen flickering problems may be the
victims of incompatible applications or defective hardware. Let’s
deep dive into the many reasons why your laptop screen has
started flickering.


background image

How to Stop Laptop Screen Flickering

Why is my laptop screen flickering?

1.

APP INCOMPATIBILITY

Personalizing your PC into your own unique digital hub means
downloading all of your favourite applications and programs. In
certain cases, your PC won’t be able to handle the parameters and
specs of certain applications which can cause screen flickering.

In order to figure out if an incompatible app is responsible for your
laptop screen flickering, follow these three easy steps.


background image

How to Stop Laptop Screen Flickering

Why is my laptop screen flickering?

1.

APP INCOMPATIBILITY

Personalizing your PC into your own unique digital hub means downloading all of your
favourite applications and programs. In certain cases, your PC won’t be able to handle
the parameters and specs of certain applications which can cause screen flickering.

In order to figure out if an incompatible app is responsible for your laptop screen
flickering, follow these three easy steps.

Step 1.

Access your task manager by pressing

CTRL + ALT + DEL

and selecting

Task Manager

.” You

can also right-click the Windows taskbar and find the task manager there.

Step 2

With the task manager open, watch your screen for any flickering. If everything on the

screen flickers except the task manager, then you’ve got an incompatible app living on your PC
.

Step 3

If the task manager flickers during your observation then you’re likely dealing with a

separate issue.


background image

How to Stop Laptop Screen Flickering

Why is my laptop screen flickering?

2. OUTDATED PC DISPLAY DRIVERS

It’s easy to neglect Windows software updates, especially when you
know how long they’ll take. Those in the habit of putting their
computer to sleep rather than shutting it down are more susceptible
to the effects of outdated drivers

Malfunctioning internal devices can lead to poor display resolutions,
glitchy internet connectivity and of course, a flickering laptop
screen. Both visual aspects and functionality in PC components
suffer the consequences of outdated drivers when patches, updates,
and bug fixes go by the wayside.

Wondering if your PC is due for an update? Check the status of your
Windows 10 operating system in five easy steps.


background image

How to Stop Laptop Screen Flickering

Why is my laptop screen flickering?

2. OUTDATED PC DISPLAY DRIVERS

Step 1.

Press the Windows taskbar button and press the gear symbol to

access your PC settings.

Step 2:

Select

Update & Security

” tab.

Step 3.

If your PC has scanned for available updates recently, you may see a

list of pending installs alongside the names of programs, extensions, or
drivers that need immediate updating.

Step 4.

If your PC has not completed an automated scan, you will be able to

select “

Check for updates.”

This will sweep your hardware and operating

system for any necessary updates.

Step 5.

Click “

Install updates

” and let your PC do the rest.


background image

How to Stop Laptop Screen Flickering

How do I fix a flickering laptop screen?

Figuring out the reason behind your flickering laptop screen will
better assist you in your efforts to finding an easy DIY solution. Since
a blinking screen can ruin the PC user experience, you’ll want a
quick-fix ASAP. Use these 5 solutions to nip that buggy screen in the
bud.

1. UPDATE YOUR DISPLAY DRIVER
In order to properly update your computer’s display driver, you’ll
need to start your computer up on Safe Mode, uninstall your current
display adapter, and check for driver updates. This three-part, 10-
step process will do the trick.


background image

How to Stop Laptop Screen Flickering

How do I fix a flickering laptop screen?

How to boot in Safe Mode

Step 1.

Press the Windows taskbar button and press the gear symbol to access your

PC settings.

Step 2.

Select “

Updates & Security

.”

Step 3.

On the left-side taskbar, select “

Recovery

.”

Step 4.

Under “

Advanced startup

” select “

Restart now

.” This will reboot your

computer and send you to a blue troubleshoot screen that lets you manage
everything from startup repairs to system restores.

Step 5.

Select “

Advanced options

.”

Step 6.

Select “

Startup Settings

,” and press “

Restart

.”

Step 7.

Once your PC reboots, select option #4 using number keys or function keys 1-

9 to “

Enable Safe Mode

.”


background image

How to Stop Laptop Screen Flickering

How do I fix a flickering laptop screen?

How to uninstall the current display driver

Step 1.

To uninstall your current display driver in safe mode, right-click your Windows

taskbar to access the Power User menu.

Step 2.

Select “

Device Manager

.”

Step 3.

Within the device manager window, extend the “

Display adapters

” tab to

reveal your PC’s active display devices.

Step 4.

Right-click the name of your current display adapter to access an operations

task list.

Step 5.

Press “

Uninstall device.”

Step 6.

A new box will pop-up, giving you the option to “

delete the driver software

for this device

.”

Step 7.

Check this box off, and press “

Uninstall

.”


background image

How to Stop Laptop Screen Flickering

How do I fix a flickering laptop screen?

How to reinstall display drivers

Step 1.

Open settings from the Power User menu again (right-

clicking the Windows taskbar icon).

Step 2.

Select “

Update & security

.”

Step 3.

Under the “

Windows Update

” tab, select “

Check for

updates

” to download and install the most up-to-date display driver.


background image

Troubleshooting Black Screen Displays with No Error Messages During Startup or Boot

Troubleshooting Black Screen Displays
with No Error Messages During Startup or Boot

❖ There are many reasons that a computer does not startup or

boot into the Windows operating system. If your computer will
not start or boot, you will see or hear symptoms to indicate the
general area of the problem

❖ Startup Symptom: LEDs glow, but computer fails to startup or

boot, and displays a black screen

❖ Use this document if the LEDs glow to indicate that power is

available and the sound of a fan or spinning hard drive can be
heard, but no colors, images, or text are displayed on the LCD
display.


background image

Troubleshooting Black Screen Displays with No Error Messages During Startup or Boot

Troubleshooting Black Screen Displays
with No Error Messages During Startup or Boot

❖ Do not use this document if there are no sounds from

the computer when the power is turned on. You should
check for a different problem; such as a loose RAM
memory chip or disconnected hard drive.

❖ The cause of this problem may be the failure of a

hardware component, or an error in the instruction
being sent from the BIOS to a hardware component.


background image

Troubleshooting Black Screen Displays with No Error Messages During Startup or Boot

Troubleshooting Black Screen Displays
with No Error Messages During Startup or Boot

Before you begin troubleshooting your computer

Before you begin troubleshooting your computer, perform the following steps:

Step one: Perform a hard reset

If your computer suddenly fails to boot properly, you should perform a hard reset.

1.Disconnect all peripheral devices and remove all USB devices and media cards

. You

want to test the computer not the accessories!

1.Disconnect the AC power adapter, remove the battery, and then press and hold the
power button for at least 15 seconds
.

2.Reconnect the AC power adapter (but do not connect the battery), Press the Power
button, Look for glowing LEDs near caps lock and num lock keys, and Listen
for
sounds of a disk drive and fan turning.


background image

Troubleshooting Black Screen Displays with No Error Messages During Startup or Boot

Troubleshooting Black Screen Displays
with No Error Messages During Startup or Boot

❖ If the display remains blank (black screen or white

screen) after doing a hard reset, temporarily connect an
external monitor to test the notebook's display

❖ If an image displays on the external monitor, continue to

perform the tests, install drivers, and make adjustments
as described in the next section.


background image

Troubleshooting Black Screen Displays with No Error Messages During Startup or Boot

Troubleshooting Black Screen Displays
with No Error Messages During Startup or Boot

❑ Step two: Connect an external monitor to test the display

1. If there are no sounds from the computer when the power is turned on, check for a
different problem; such as a loose RAM memory chip or disconnected hard drive.

2. If you are having trouble viewing the external monitor, click f4 (or the key with this
symbol  ) to switch the screen image among display devices connected to the system. For
example, if a monitor is connected to the computer, pressing this key alternates the
screen image from computer display to monitor display to simultaneous display on both
the computer and the monitor.

3. If an image displays on the external monitor, there may be a graphics driver conflict
with the notebook’s LCD display. With the external monitor connected, download and
install the latest drivers for your specific computer and graphic chip set.

4. If you do not have an external monitor, it may be possible to see an image by switching
the LCD display to a low resolution mode. To change the resolution, turn on the
computer, and press the f8 key. If the graphic display is working at the BIOS level, a text
screen displays and you can select the Enable low-resolution video option. If the graphics
display is not working at the BIOS level, contact an authorized repair center.


background image

Troubleshooting Black Screen Displays with No Error Messages During Startup or Boot

Troubleshooting Black Screen Displays
with No Error Messages During Startup or Boot

❑ As a final action, if there is an image on the external monitor and you have

installed the latest BIOS, updated CPU chips set, and updated graphics
drivers but the notebook display remains black, the LCD may be defective. It
may be necessary to contact HP for technical assistance or send the
notebook for service to replace the display.

❑ Step three: Disconnect all peripherals and repeat the hard reset

❖ Even when instructed to disconnect all peripheral devices from the notebook before

doing a hard reset, some devices are often overlooked.

Double-check that all devices are disconnected including: external keyboard and mouse
(wired or wireless), USB connected external drives and devices, thumb drives and flash
drives, network storage devices, PC card, SD memory cards, express card, eSata
connections, firewire or similar devices, printer, scanner, camera, port replicator, or
docking station, any CD/DVD from the optical disc drive, and any media from the multi-
card reader.


background image

Troubleshooting Black Screen Displays with No Error Messages During Startup or Boot

Troubleshooting Black Screen Displays
with No Error Messages During Startup or Boot

❑ Test for memory module problems

❖ When you try to turn on a computer, one of the first hardware tests performed is the

memory check. If the start up test cannot access the memory chips, the testing stops
and no additional actions can be taken. In other words, when you press the power
button the LEDs may glow for a moment and a fan may start to spin, but then all
action stops.

1. Check for loose memory modules

2. Test two memory modules

3. Test two memory slots

4. Test for memory problems using HP PC Hardware Diagnostics

❖ The Memory Tests include a Fast Test, Quick Test, and an Extensive Test. If you think there is a problem with the

memory, first try the Fast Test (3 to 5 minutes). If the Fast Test does not find a problem, run the Quick Test (about 10
minutes). If the Quick Test does not find a problem, run the Extensive Test (about 45 minutes) which also has a Loop
Until Error option.


background image

Troubleshooting Black Screen Displays with No Error Messages During Startup or Boot

Troubleshooting Black Screen Displays
with No Error Messages During Startup or Boot

❑ Test for memory module problems

NOTE: For information on the HP PC Hardware Diagnostics, including
installation instructions for the latest version,

see HP PCs - Testing for

Hardware Failures.

Follow these steps to run the Fast Test:

1.Hold the power button for at least five seconds to turn off the computer.

2.Turn on the computer and immediately press Esc repeatedly, about once
every second. When the menu appears, press the F2 key.


background image

Troubleshooting Black Screen Displays with No Error Messages During Startup or Boot

Troubleshooting Black Screen Displays
with No Error Messages During Startup or Boot

❑ Test for memory module problems


background image

Troubleshooting Black Screen Displays with No Error Messages During Startup or Boot

Troubleshooting Black Screen Displays
with No Error Messages During Startup or Boot

❑ Test for memory module problems


background image

Troubleshooting Black Screen Displays with No Error Messages During Startup or Boot

Troubleshooting Black Screen Displays
with No Error Messages During Startup or Boot

❑ Test for memory module problems


background image

How Do I Fix a Laptop that Won’t Turn On?

How Do I Fix a Laptop that Won’t Turn On?

❖ You press the power button on your laptop... and nothing

happens.

There are few more frustrating technological hiccups than when
your laptop won’t turn on. However, you don’t have to resign
yourself to the idea that your laptop has met an untimely death.
We’ll show you some ways to assess what’s wrong and fix it.

❖ If your laptop won’t power up, a faulty power supply, failed

hardware, or a malfunctioning screen could be to blame [1]. In
many cases, you may be able to resolve the problem yourself by
ordering replacement parts or adjusting your laptop’s
configuration.

But if your laptop is older and the problem is an expensive hardware
issue, it may make be the best time to buy a new laptop.


background image

How Do I Fix a Laptop that Won’t Turn On?

How Do I Fix a Laptop that Won’t Turn On?

1.

Check the power supply and battery

If your HP laptop won’t turn on even when plugged in, start by checking the
power supply. There are quite a few issues you could have with the power
supply.

For example, the problem could be as simple as having the wrong charging
cord which means you aren’t getting the proper voltage, or it could be that
the power supply has failed [2].

1. To test if the power supply is the issue, completely remove your laptop
battery.

2. Then, plug your laptop into a functioning outlet.

3. First, confirm the outlet is functioning properly by plugging another
device into it - if it works, the issue isn’t the outlet.


background image

How Do I Fix a Laptop that Won’t Turn On?

How Do I Fix a Laptop that Won’t Turn On?

2. Remove all devices from your laptop

If you have left a memory card, DVD, or USB drive in your notebook, this could
be a reason why your laptop doesn’t power on.
It might be getting “stuck” because the BIOS may be trying to boot from a
removable storage device. Remove all USB drives and other devices and try to
boot up your computer.

3. Use a rescue disc

A rescue disc allows you to boot your computer and fix any issues you may be
having with a Windows operating system [5]. If a virus is the culprit behind your
computer problems, the rescue disc will find it via scanning tools so you can
remove the offending malware.


background image

How Do I Fix a Laptop that Won’t Turn On?

How Do I Fix a Laptop that Won’t Turn On?

5. Boot in safe mode

If your HP laptop won’t turn on you might still be able to get your laptop working in safe
mode [6]. Safe mode allows you to uninstall new programs or drivers that could be
affecting your laptop. It also allows you to create a new user account if your original
account has been corrupted.

6. Check hardware

The last step when diagnosing power issues is to check your hardware. If you’ve recently
installed hardware like a new RAM kit, that could be the cause of your boot issues.
Remove and reinstall your new hardware and try to boot again.
Unfortunately, sometimes the hardware in your laptop such as your hard drive simply fails
and there is no easy fix. If you hear a clicking noise or the drive spinning but then
powering down, this is a telltale sign your hard drive has failed [7]. In most cases, this
means you’ll need to simply replace your hard drive.
In instances like this, it is smart to have an external hard drive so you can back up any files
you may need.


background image

Contact 1000FiX

76

Also, can check your product status update from this link

https://1000fix.com/OrderTracking

Level 1:

Call at Contact center (09610001015, 09604300600 or

16743

)

Email at corporate.support@1000fix.com for any service request or query

Level 2:

Md. Ahsanul Haque Rony (01730701947) – Customer Relationship Manager,
Corporate Operation

Level 3:

M. Mohiuddin (01730317700) – Manager, Corporate Operation

Level 4:

Rizwanul Hoque Chowdhury (01730317713) – General Manager, Head of Operation

For any bulk spare parts procurement or new IT product
installation/commissioning,

please contact ferdous.mijan@1000fix.com or tamim.ahmed@1000fix.com


background image

Thank you
